Invi-Pin 50
SKU: INVI-PIN-50Bottom openable pin spot fixed LED down light. The architectural intent is that you see the light and not the fitting. Light output: 6W–15W (5 options), 2700K–4000K @ 97CRI (8 options), CRI >90 / >97, 24° / 36° / 50° beam. Ceiling recessed installation, rated for indoor use, IP20. Control gear: Non-Dim, Dali, Phase Cut, 0-10V/1-10V Analogue, RF, Zigbee, Ble (mesh), Casambi and DMX. For general and accent ceiling lighting in retail, hospitality and residential interiors, on a regular grid or tuned to specific targets. Made by Abner Lighting in Mumbai — designed, engineered and finished in-house.
Technical Data
- Wattage
- 6W / 8W / 10W / 12W / 15W
- Beam Angle
- 24° / 36° / 50°
- CCT
- 90CRI → 2700K / 3000K / 3500K / 4000K / 5000K97CRI → 2700K / 3000K / 3500K / 4000K
- CRI
- >90 / >97
- Mounting
- Ceiling Recessed
- Environment
- Indoor
- IP Rating
- IP20
- Driver
- Non-Dim, Dali, Phase Cut, 0-10V/1-10V Analogue, RF, Zigbee, Ble (mesh), Casambi and DMX
