Invi-WW 70
SKU: INVI-WW-70Bottom openable anti-glare (asymmetrical wall washer) light. An engineered luminaire first — the housing exists to control glare, hold alignment and disappear into the ceiling plane. Light output: 6W–15W (5 options), 2700K–4000K @ 97CRI (8 options), CRI >90 / >97, asymmetric. Ceiling recessed installation, rated for indoor use, IP20. Control gear: Non-Dim, Dali, Dali DT-8 (TW), Phase Cut, 0-10V/1-10V Analogue, RF, Zigbee, Ble (mesh), Casambi and DMX. Aimed at vertical surfaces — stone cladding, gallery walls, feature joinery — to light the plane evenly rather than pooling on the floor.
Technical Data
- Wattage
- 6W / 8W / 10W / 12W / 15W
- Beam Angle
- Asymmetric
- CCT
- 90CRI → 2700K / 3000K / 3500K / 4000K / 5000K97CRI → 2700K / 3000K / 3500K / 4000K
- Special CCT
- 90CRI → 1800K-3000K TW / 1800K-4000K (2700K-6500K TW Max 15W)
- CRI
- >90 / >97
- Mounting
- Ceiling Recessed
- Environment
- Indoor
- IP Rating
- IP20
- Driver
- Non-Dim, Dali, Dali DT-8 (TW), Phase Cut, 0-10V/1-10V Analogue, RF, Zigbee, Ble (mesh), Casambi and DMX
